This! Is! Singularity!
Gave Singularity another try, after letting the dust settle on a previous traumatic experience, expecting it not to work AT ALL and being astounded and also unsurprised that it actually worked with minimal effort.
The target: the wonderful ggCaller (https://github.com/samhorsfield96/ggCaller).
A Singularity image (.sif) was already provided by the developer (https://zenodo.org/records/7870950), although it should be possible to wrangle Docker images into Singularity format with a theoretically simple conversion.
#load Singularity
module load singularity/3.10.5
singularity -h
Linux container platform optimized for High Performance Computing (HPC) and
Enterprise Performance Computing (EPC)
Usage:
singularity [global options...]
Description:
Singularity containers provide an application virtualization layer en abling
mobility of compute via both application and environment portability. With
Singularity one is capable of building a root file system that runs o n any
other Linux system where Singularity is installed.
Options:
-c, --config string specify a configuration file (for root or
unprivileged installation only) (default
"/install/software/restart/depos/singularity/in stallation//etc/singularity/singularity.conf")
-d, --debug print debugging information (highest verbosity)
-h, --help help for singularity
--nocolor print without color output (default False)
-q, --quiet suppress normal output
-s, --silent only print errors
-v, --verbose print additional information
--version version for singularity
Available Commands:
build Build a Singularity image
cache Manage the local cache
capability Manage Linux capabilities for users and groups
completion Generate the autocompletion script for the specified shel l
config Manage various singularity configuration (root user only)
delete Deletes requested image from the library
exec Run a command within a container
help Help about any command
inspect Show metadata for an image
instance Manage containers running as services
key Manage OpenPGP keys
oci Manage OCI containers
overlay Manage an EXT3 writable overlay image
plugin Manage Singularity plugins
pull Pull an image from a URI
push Upload image to the provided URI
remote Manage singularity remote endpoints, keyservers and OCI/D ocker registry credentials
run Run the user-defined default command within a container
run-help Show the user-defined help for an image
search Search a Container Library for images
shell Run a shell within a container
sif Manipulate Singularity Image Format (SIF) images
sign Attach digital signature(s) to an image
test Run the user-defined tests within a container
verify Verify cryptographic signatures attached to an image
version Show the version for Singularity
Examples:
$ singularity help <command> [<subcommand>]
$ singularity help build
$ singularity help instance start
For additional help or support, please visit https://www.sylabs.io/docs /
The first issue, which had cropped up previously, related to the absence of suitable cache dir:
FATAL: Failed to create an image cache handle: failed initializing caching directory: couldn't create cache directory /home/ulrich.schnauss/.singularity/cache: mkdir /home/ulrich.schnauss/.singularity: disk quota exceeded
which could be resolved by redefining the environmental variable to point towards a new folder on my analysis drive.
export SINGULARITY_CACHEDIR="/path/to/my/analysis/folder/singularity/"
Then, it was possible to smash the bottle against the hull and pull my first container:
wget https://zenodo.org/records/7870950/files/samhorsfield96_ggcaller_latest-2023-04-27-6c0a454e1c5c.sif?download=1
mv https://zenodo.org/records/7870950/files/samhorsfield96_ggcaller_latest-2023-04-27-6c0a454e1c5c.sif?download=1 https://zenodo.org/records/7870950/files/samhorsfield96_ggcaller_latest-2023-04-27-6c0a454e1c5c.sif
Tried to build it per the wiki instructions:
singularity shell --writable samhorsfield96_ggcaller_latest-2023-04-27-6c0a454e1c5c.sif
FATAL: no SIF writable overlay partition found in /path/to/my/analysis/folder/singularity/samhorsfield96_ggcaller_latest-2023-04-27-6c0a454e1c5c.sif
Thankfully, someone had experienced a similiar issue before and left their documentation up in the annals of the interwebs #shouldersofgiants: https://groups.google.com/a/lbl.gov/g/singularity/c/HhwetRXIfYI/m/6RP4N5zBAAAJ
singularity build --sandbox samhorsfield96_ggcaller_latest-2023-04-27-6c0a454e1c5c.sif
Build target 'samhorsfield96_ggcaller_latest-2023-04-27-6c0a454e1c5c.sif' already exists and will be deleted during the build process. Do you want to continue? [N/y] y
INFO: Starting build...
INFO: Creating sandbox directory...
INFO: Build complete: samhorsfield96_ggcaller_latest-2023-04-27-6c0a454e1c5c.sif
That was… it? 100% believing it would not work, proceeded to amend PATH as per the instructions and navigated inside the folder
PATH=$PATH:/opt/conda/bin
cd samhorsfield96_ggcaller_latest-2023-04-27-6c0a454e1c5c.sif
#I think the naming/structuring could be improved here for future, on my part
ggcaller -h
usage: ggcaller [-h] [--graph GRAPH] [--colours COLOURS] [--not-ref]
[--refs REFS] [--reads READS] [--query QUERY]
[--codons CODONS] [--kmer KMER] [--save]
[--data DATA] [--all-seq-in-graph] [--out OUT]
[--max-path-length MAX_PATH_LENGTH]
[--min-orf-length MIN_ORF_LENGTH]
[--score-tolerance SCORE_TOLERANCE]
[--max-ORF-overlap MAX_ORF_OVERLAP]
[--min-path-score MIN_PATH_SCORE]
[--min-orf-score MIN_ORF_SCORE]
[--max-orf-orf-distance MAX_ORF_ORF_DISTANCE]
[--query-id QUERY_ID] [--no-filter] [--no-write-idx]
[--no-write-graph] [--repeat] [--no-clustering]
[--no-refind] [--identity-cutoff IDENTITY_CUTOFF]
[--len-diff-cutoff LEN_DIFF_CUTOFF]
[--family-threshold FAMILY_THRESHOLD]
[--merge-paralogs]
[--clean-mode {strict,moderate,sensitive}]
[--annotation {none,fast,sensitive,ultrasensitive}]
[--diamonddb ANNOTATION_DB] [--hmmdb HMM_DB]
[--evalue EVALUE]
[--truncation-threshold TRUNCATION_THRESHOLD]
[--search-radius SEARCH_RADIUS]
[--refind-prop-match REFIND_PROP_MATCH]
[--min-trailing-support MIN_TRAILING_SUPPORT]
[--trailing-recursive TRAILING_RECURSIVE]
[--edge-support-threshold EDGE_SUPPORT_THRESHOLD]
[--length-outlier-support-proportion LENGTH_OUTLIER_SUP PORT_PROPORTION]
[--min-edge-support-sv MIN_EDGE_SUPPORT_SV]
[--no-clean-edges] [--alignment {core,pan}]
[--aligner {def,ref}] [--core-threshold CORE]
[--no-variants] [--ignore-pseduogenes] [--quiet]
[--threads THREADS] [--version]
Generates ORFs from a Bifrost graph.
optional arguments:
-h, --help show this help message and exit
Input/Output options:
--graph GRAPH Bifrost GFA file generated by Bifrost build.
--colours COLOURS Bifrost colours file generated by Bifrost
build.
--not-ref If using existing graph, was not graph built
exclusively with assembled genomes. [Default
= False]
--refs REFS List of reference genomes (one file path per
line).
--reads READS List of read files (one file path per line).
--query QUERY List of unitig sequences to query (either
FASTA or one sequence per line)
--codons CODONS JSON file containing start and stop codon
sequences.
--kmer KMER K-mer size used in Bifrost build (bp).
[Default = 31]
--save Save graph objects for sequence querying.
[Default = False]
--data DATA Directory containing data from previous
ggCaller run generated via "--save"
--all-seq-in-graph Retains all DNA sequence for each gene
cluster in the Panaroo graph output. Off by
default as it uses a large amount of space.
--out OUT Output directory
ggCaller traversal and gene-calling cut-off settings:
--max-path-length MAX_PATH_LENGTH
Maximum path length during ORF finding (bp).
[Default = 20000]
--min-orf-length MIN_ORF_LENGTH
Minimum ORF length to return (bp). [Default =
90]
--score-tolerance SCORE_TOLERANCE
Length probability tolerance for shorter
alternative start sites. If within
tolerance,ggCaller will check if start
coverage and BALROG score are both higher in
shorter ORF. [Default = 0.2]
--max-ORF-overlap MAX_ORF_OVERLAP
Maximum overlap allowed between overlapping
ORFs. [Default = 60]
--min-path-score MIN_PATH_SCORE
Minimum total Balrog score for a path of ORFs
to be returned. [Default = 100]
--min-orf-score MIN_ORF_SCORE
Minimum individual Balrog score for an ORF to
be returned. [Default = 100]
--max-orf-orf-distance MAX_ORF_ORF_DISTANCE
Maximum distance for graph traversal during
ORF connection (bp). [Default = 10000]
--query-id QUERY_ID Ratio of query-kmers to required to match in
graph. [Default = 0.8]
Settings to avoid/include algorithms:
--no-filter Do not filter ORF calls using Balrog. Will
return all ORF calls. [Default = False]
--no-write-idx Do not write FMIndexes to file. [Default =
False]
--no-write-graph Do not write Bifrost GFA and colours to file.
[Default = False]
--repeat Enable traversal of nodes multiple times.
[Default = False]
--no-clustering Do not cluster ORFs. [Default = False]
--no-refind Do not refind uncalled genes [Default =
False]
Gene clustering options:
--identity-cutoff IDENTITY_CUTOFF
Minimum identity at amino acid level between
two ORFs for clustering. [Default = 0.98]
--len-diff-cutoff LEN_DIFF_CUTOFF
Minimum ratio of length between two ORFs for
clustering. [Default = 0.98]
--family-threshold FAMILY_THRESHOLD
protein family sequence identity threshold
[Default = 0.7]
--merge-paralogs don't split paralogs[Default = False]
Panaroo run mode options:
--clean-mode {strict,moderate,sensitive}
R|The stringency mode at which to run
panaroo. Must be one of 'strict', 'moderate'
or 'sensitive'. Each of these modes can be
fine tuned using the additional parameters in
the 'Graph correction' section. strict:
Requires fairly strong evidence (present in
at least 5% of genomes) to keep likely
contaminant genes. moderate: Requires
moderate evidence (present in at least 1% of
genomes) to keep likely contaminant genes.
sensitive: Does not delete any genes and only
performes merge and refinding operations.
Useful if rare plasmids are of interest as
these are often hard to disguish from
contamination. Results will likely include
higher number of spurious annotations.
Panaroo gene cluster annotation options:
--annotation {none,fast,sensitive,ultrasensitive}
Annotate genes using diamond default (fast),
diamond sensitive (sensitive) or diamond and
HMMscan (ultrasensitive). Specify 'none' if
annotation not required.Default = 'fast'
--diamonddb ANNOTATION_DB
Diamond database. Defaults are 'Bacteria' or
'Viruses'. Can also specify path to fasta
file for custom database generation
--hmmdb HMM_DB HMMER hmm profile file. Default is Uniprot
HAMAP. Can alsospecify path to pre-built hmm
profile file generated using hmmbuild
--evalue EVALUE Maximum e-value to return for DIAMOND and
HMMER searches during annotation[Default =
0.001]
--truncation-threshold TRUNCATION_THRESHOLD
Sequences in a gene family cluster below this
proportion of the length of thecentroid will
be annotated as 'potential
pseudogene'[Default = 0.8]
Panaroo gene refinding options:
--search-radius SEARCH_RADIUS
the distance in nucleotides surronding the
neighbour of an accessory gene in which to
search for it
--refind-prop-match REFIND_PROP_MATCH
the proportion of an accessory gene that must
be found in order to consider it a
match[Default = 0.2]
Panaroo graph correction stringency options:
--min-trailing-support MIN_TRAILING_SUPPORT
minimum cluster size to keep a gene called at
the end of a contig
--trailing-recursive TRAILING_RECURSIVE
number of times to perform recursive trimming
of low support nodes near the end of contigs
--edge-support-threshold EDGE_SUPPORT_THRESHOLD
minimum support required to keep an edge that
has been flagged as a possible mis-assembly
--length-outlier-support-proportion LENGTH_OUTLIER_SUPPORT_PROPORTION
proportion of genomes supporting a gene with
a length more than 1.5x outside the
interquatile range for genes in the same
cluster.Genes failing this test will be re-
annotated at the shorter length[Default =
0.1]
--min-edge-support-sv MIN_EDGE_SUPPORT_SV
minimum edge support required to call
structural variants in the presence/absence
sv file
--no-clean-edges Turn off edge filtering in the final output
graph.[Default = False]
Alignment options:
--alignment {core,pan}
Output alignments of core genes or all genes.
Options are 'core' and 'pan'. [Default =
'None'
--aligner {def,ref} Specify an aligner. Options: 'ref' for
reference-guided MSA and 'def' for default
standard MSA
--core-threshold CORE
Core-genome sample threshold.[Default = 0.95]
--no-variants Do not call variants using SNP-sites after
alignment.[Default = False]
--ignore-pseduogenes Ignore ORFs annotated as 'potential
pseudogenes' in alignment[Default = False]
Misc. options:
--quiet suppress additional output[Default = False]
--threads THREADS Number of threads to use. [Default = 1]
--version, -v show program's version number and exit
So there you have it: what took the bones of a day to install through the refiners fire that is Conda dependency hell, resolved in 10 mins. Still need to suss out how to use Docker images where the devs haven’t already generated a Singularity file…
<
Previous Post
Quickly jotting down notes to use AWS-CLI and PAT to resolve issues installing R packages from Github today…
>
Next Post
Trying to do a post per week, despite it being absolutely hectic these days, and needed to install Palmscan (https://github.com/rcedgar/palmscan) locally in the line of peer review.
